Description

Skid mounted high pressure nitrogen pumper made by hydra rig
unit specs
diesel engine 500hp
lifting skid
exhaust gases heat recovery system
high pressure cryogenic triplex pump
high pressure vaporizing system
hydraulic driven system
hydraulic brake
control system
automatic alarms and shutdowns (n2 high press., oil low press, water high temp.)
Low pressure manifold and centrifuge feeding pump
piping
all cryogenic piping (suction and discharge) type 304 or 316
stainless steel
high pressure piping and valves
operating and maintenance manual
general arrangement drawing
hydraulic schematic
nitrogen piping schematic
coolant schematic
control panel arrangement drawing
lube oil schematic
components certifications and original instructions
original part numbers
maximum working pressure 690bar (10,000 psi)
hydrostatic test pressure 1034bar (15,000 psi)
maximum flow rate 180,000 scfh
